BEL/BES - угол 90°
Уточнить цену
Фитинги для РВД BEL/BES - угол 90° - ISO 8434-1 (DIN 2353)
Характеристики
| Артикул | Бренд | DN | DASH | ID (дюйм) | D1 | L1 | L2 | L3 | WP (bar) |
| 801401 | CAST | 5 | -3 | 3/16 | 6L/S | 37 | 21.5 | 19 | 415 |
| 801402 | CAST | 5 | -3 | 3/16 | 8L/S | 38.5 | 21.5 | 22.5 | 415 |
| 801403 | CAST | 6 | -4 | 1/4 | 6L/S | 37 | 21.5 | 19 | 450 |
| 801404 | CAST | 6 | -4 | 1/4 | 8L/S | 38.5 | 21.5 | 22.5 | 450 |
| 801405 | CAST | 6 | -4 | 1/4 | 10L/S | 37.5 | 21.5 | 21.5 | 450 |
| 801406 | CAST | 6 | -4 | 1/4 | 12L/S | 42.5 | 21.5 | 25.5 | 450 |
| 801407 | CAST | 8 | -5 | 5/16 | 10L/S | 43.5 | 26 | 21.5 | 350 |
| 801408 | CAST | 8 | -5 | 5/16 | 12L/S | 47.5 | 26 | 25.5 | 350 |
| 801409 | CAST | 10 | -6 | 3/8 | 10L/S | 46.5 | 29.5 | 21.5 | 445 |
| 801410 | CAST | 10 | -6 | 3/8 | 12L/S | 50.5 | 29.5 | 25.5 | 445 |
| 801411 | CAST | 10 | -6 | 3/8 | 14S | 48.5 | 29.5 | 23.5 | 445 |
| 801412 | CAST | 10 | -6 | 3/8 | 15L | 48 | 29.5 | 23 | 315 |
| 801413 | CAST | 12 | -8 | 1/2 | 14S | 52.5 | 36 | 23.5 | 415 |
| 801414 | CAST | 12 | -8 | 1/2 | 15L | 52 | 36 | 23 | 315 |
| 801415 | CAST | 12 | -8 | 1/2 | 16S | 53 | 36 | 24 | 400 |
| 801416 | CAST | 12 | -8 | 1/2 | 18L | 50.5 | 36 | 21.5 | 315 |
| 801417 | CAST | 16 | -10 | 5/8 | 18L | 54.5 | 40 | 21.5 | 315 |
| 801418 | CAST | 16 | -10 | 5/8 | 20S | 61 | 40 | 28 | 350 |
| 801419 | CAST | 19 | -12 | 3/4 | 20S | 72 | 47 | 28 | 350 |
| 801420 | CAST | 19 | -12 | 3/4 | 22L | 66.5 | 47 | 22.5 | 160 |
| 801421 | CAST | 19 | -12 | 3/4 | 25S | 75 | 47 | 31 | 350 |
| 801422 | CAST | 25 | -16 | 1 | 25S | 79 | 63 | 31 | 280 |
| 801423 | CAST | 25 | -16 | 1 | 28L | 72 | 63 | 24 | 160 |
| 801424 | CAST | 25 | -16 | 1 | 30S | 82 | 63 | 34 | 280 |
| 801425 | CAST | 31 | -20 | 1.1/4 | 35L | 94.5 | 75.5 | 30.5 | 160 |
| 801427 | CAST | 38 | -24 | 1.1/2 | 38S | 117.5 | 101 | 40 | 185 |
| 801428 | CAST | 38 | -24 | 1.1/2 | 42L | 110 | 101 | 32.5 | 160 |
