BEL/BES
Уточнить цену
Фитинги для РВД BEL/BES - ISO 8434-1 (DIN 2353)
Характеристики
| Артикул | Бренд | DN | DASH | ID (дюйм) | D1 | L1 | L2 | WP (bar) |
| 701303 | CAST | 6 | -4 | 1/4 | 6L/S | 24.5 | 19 | 450 |
| 701305 | CAST | 6 | -4 | 1/4 | 10L/S | 27 | 21.5 | 450 |
| 701306 | CAST | 6 | -4 | 1/4 | 12L/S | 31 | 25.5 | 450 |
| 701307 | CAST | 8 | -5 | 5/16 | 10L/S | 27.5 | 21.5 | 350 |
| 701312 | CAST | 10 | -6 | 3/8 | 15L | 29 | 23 | 315 |
| 701318 | CAST | 16 | -10 | 5/8 | 20S | 34.5 | 28 | 350 |
| 701321 | CAST | 19 | -12 | 3/4 | 25S | 38 | 31 | 350 |
| 701325 | CAST | 31 | -20 | 1.1/4 | 35L | 39.5 | 30.5 | 160 |
| 801301 | CAST | 5 | -3 | 3/16 | 6L/S | 24.5 | 19 | 415 |
| 801302 | CAST | 5 | -3 | 3/16 | 8L/S | 28 | 22.5 | 415 |
| 801304 | CAST | 6 | -4 | 1/4 | 8L/S | 28 | 22.5 | 450 |
| 801308 | CAST | 8 | -5 | 5/16 | 12L/S | 31.5 | 25.5 | 350 |
| 801309 | CAST | 10 | -6 | 3/8 | 10L/S | 27.5 | 21.5 | 445 |
| 801310 | CAST | 10 | -6 | 3/8 | 12L/S | 31.5 | 25.5 | 445 |
| 801311 | CAST | 10 | -4 | 3/8 | 14S | 29.5 | 23.5 | 445 |
| 801313 | CAST | 12 | -8 | 1/2 | 14S | 29.5 | 23.5 | 415 |
| 801314 | CAST | 12 | -8 | 1/2 | 15L | 29 | 23 | 315 |
| 801315 | CAST | 12 | -8 | 1/2 | 16S | 30 | 24 | 400 |
| 801316 | CAST | 12 | -8 | 1/2 | 18L | 27.5 | 21.5 | 315 |
| 801317 | CAST | 16 | -10 | 5/8 | 18L | 28 | 21.5 | 315 |
| 801319 | CAST | 19 | -12 | 3/4 | 20S | 35 | 28 | 350 |
| 801320 | CAST | 19 | -12 | 3/4 | 22L | 29.5 | 22.5 | 160 |
| 801322 | CAST | 25 | -16 | 1 | 25S | 39 | 31 | 280 |
| 801323 | CAST | 25 | -16 | 1 | 28L | 32 | 24 | 160 |
| 801324 | CAST | 25 | -16 | 1 | 30S | 42 | 34 | 280 |
| 801326 | CAST | 31 | -20 | 1.1/4 | 38S | 49 | 40 | 210 |
| 801327 | CAST | 38 | -24 | 1.1/2 | 38S | 50 | 40 | 185 |
| 801328 | CAST | 38 | -24 | 1.1/2 | 42L | 42.5 | 32.5 | 160 |
